Conveyors

Flexible capacity at any location

In addition to the standard telescopic conveyors, Bijlsma Hercules offers a similar model in single version. These conveyors are easy to use in places where capacity is required. Whether it concerns reading a batch or bridging a large distance, with the conveyors from Bijlsma Hercules your product moves from A to B fast.

Usable anywhere

Conveyors can be used as an extra inspection conveyor and can easily be used when turning boxes where the product has to be turned shortly apart. Due to an extremely stable frame, the machine can be easily moved over rough terrain and proper operation is guaranteed. The conveyors are equipped with drum motors.

  • Round input-funnel with which the product can be poured into the machine from any side.
  • Two swivel castors and two fixed castors made of rubber, all Ø 200 mm.
  • Swivel castors with break for stable support and easy machine movement.
  • Height adjustement with pin/hole connection so that the machine can be adjusted to the correct height.
  • BLC Line Module System.
  • Variable speed control by means of a frequency converter at the first conveyor.
  • Castor wheels castors Ø 250 mm instead of Ø 200 mm.
  • Connection part for connection yoke (for line set-up with storage loader).
  • Line module cables for BLC Line Module System.
Model BVB 1-607 BVB 1-807 BVB 1-907 BVB 1-1207
Belt length 6.000 mm 8.000 mm 9.000 mm 12.000 mm
Belt width 700 mm 700 mm 700 mm 700 mm
Belt type rubber belt rubber belt rubber belt rubber belt
Belt shape three-part trough three-part trough three-part trough three-part trough
Belt support support rollers Ø 50 mm support rollers Ø 50 mm support rollers Ø 50 mm support rollers Ø 50 mm
Input height 860 mm 860 mm 860 mm 860 mm
Output height 980 mm 980 mm 980 mm 980 mm
Reach in front of the wheels 1.600 mm 1.600 mm 1.600 mm 1.600 mm
Belt speed 24/48 m/min. 24/48 m/min. 24/48 m/min. 24/48 m/min.
Belt drive 0.55/1.1 kW 0.55/1.1 kW 0.55/1.1 kW 0.55/1.1 kW

* Subject to technical changes.
